---Applications
As a belt auto timing belt manufacturer,synchronous belt is widely used in office machines, computers, projects, tape-records, domestic appliances, machine tools, medical equipment, and so on.Also Mistushiko is as OEM timing belt supplier ,we supply high torque timing belt,export to Japan and German.
---Property
The transmission of synchronous belt is a new transmission mode and transmits the dynamic force by the meshing of the belt teeth and pulley. It combines respective advantages of gear transmission, chain transmission and belt transmission.
Technical Specifications
| Test Item | Test Result |
|---|---|
| Tension strength (≥KN/25.4mm) | 0.59-10.8 |
| Elongation (≤%) | 4.0 |
| Type | Pitch (Pb) | Tooth Height (Ht) | Applications |
|---|---|---|---|
| ZA | 9.525mm | 1.91mm | Compact car engines |
| ZH | 9.525mm | 3.50mm | Heavy-duty trucks |
Industry-Specific Solutions
Automotive
- Engine timing systems
- Camshaft drives
- Hybrid vehicle components
Industrial
- CNC machine tools
- Packaging equipment
- Robotic arms
--- Models and types of Automotive Synchronous Timing Belt
Note: Cover thickness, cord diameter, and cord pitch can be manufactured according to customer’s requirements.
| Type | Pb(mm) | Ht(mm) | Hs(mm) |
| ZA | 9.525 | 1.91 | 4.10 |
| ZB | 9.525 | 2.29 | 4.50 |
| ZH | 9.525 | 3.50 | 5.50 |
| YH | 8.000 | 3.04 | 5.20 |
| ZR | 9.525 | 3.20 | 5.40 |
| YS | 8.000 | 2.95 | 5.20 |
| ZS | 9.525 | 3.53 | 5.70 |
| ZAS | 9.525 | 2.32 | 4.62 |
| ZBS | 9.525 | 2.80 | 2.80 |
| FS8M | 8.000 | 3.05 | 3.05 |
| YU | 8.000 | 3.11 | 3.11 |
| MY | 8.000 | 3.11 | 3.11 |
| MR | 9.525 | 3.54 | 3.54 |
| RU | 9.525 | 3.56 | 3.56 |
| ZLB | 9.525 | 2.70 | 2.70 |
| ZD | 9.525 | 3.50 | 3.50 |
