---Usage
The polyester conveyor belt is also called EP conveying belt. Its framework material is the polyester canvas interwoven with meridian terylene and latitudinal polyamide fiber. It has advantages of short tensile, stable size good elasticity, shock resistant, heat resistant mould-resistant, high adhesive strength. It is applicable to convey material in medium and long distance, with heavy-load and at high speed.
---Characteristics
|
Structure |
Textile item |
Carcass |
Tensile strength (N/mm) |
Thickness of cover rubber (mm) |
Wide range (mm) |
||||||
Warp |
Weft |
2Ply |
3Ply |
4Ply |
5Ply |
6Ply |
Top cover |
Bottom cover |
||||
EP |
Polyester |
Polyamie |
EP100 |
1 |
200 |
300 |
400 |
500 |
600 |
1.5-30 |
1.5-20 |
300-2500 |
EP125 |
1 |
250 |
375 |
500 |
625 |
750 |
1.5-30 |
1.5-20 |
300-2500 |
|||
EP150 |
1.1 |
300 |
450 |
600 |
750 |
900 |
1.5-30 |
1.5-20 |
300-2500 |
|||
EP200 |
1.2 |
400 |
600 |
800 |
1000 |
1200 |
1.5-30 |
1.5-20 |
300-2500 |
|||
EP250 |
1.4 |
500 |
750 |
1000 |
1250 |
1500 |
1.5-30 |
1.5-20 |
300-2500 |
|||
EP300 |
1.6 |
600 |
900 |
1200 |
1500 |
1800 |
2-30 |
2-20 |
300-2500 |
|||
EP350 |
1.7 |
700 |
1050 |
1400 |
1750 |
2100 |
2-30 |
2-20 |
300-2500 |
|||
EP400 |
1.9 |
800 |
1200 |
1600 |
2000 |
2400 |
2-30 |
2-20 |
300-2500 |
|||
EP500 |
2.1 |
1000 |
1500 |
2000 |
2500 |
3000 |
2-30 |
2-20 |
300-2500 |
|||
EP630 |
2.4 |
1260 |
1890 |
2520 |
3150 |
3780 |
2-30 |
2-20 |
||||
---Standard Specifications
Attention:we can produce all kinds of performance conveyor belt under DIN ,RMA ,AS ,JIK standards and so on.
Grade |
lensile strength min. (Iso37) Mpa
|
Elongation at break min. (ISo37) %
|
Abrasion max. (ISO4649) mm-
|
H |
24 |
450 |
120 |
D |
18 |
400 |
100 |
L |
15 |
350 |
200 |
